Control the 4K HDBaseT 8x8 Matrix Switcher from local
! Control the 4K HDBaseT 8x8 Matrix Switcher from remote
Control the KanexPro 8x8 Matrix Switcher from remote
4.3.6 Control 3rd-Party Device from Local
Connect the 9 pin female RS232 port of the switcher with PC, by using the RS232
command “/+[Y]/[X]:******.”, you are able to control the 3rd-party device connected with
the HDBaseT receiver.
Please refer to the detailed command descriptionin4.3.4 RS232 Communication
Commands.
