Command
Function
Feedback Example
%9976.
Check the output resolution.
Resolution
Out 1 0000x0000
Out 2 1920x1080
Out 3 1920x1080
Out 4 1920x1080
Out 5 0000x0000
Out 6 1920x1080
Out 7 1920x1080
Out 8 1920x1080
%9977.
Check the status of digital audio of output
channels.
Out 1 2 3 4
Audio Y Y Y Y
Out 5 6 7 8
Audio Y Y Y Y
%9978.
Check the HDCP compliant status of the
inputs.
In 1 2 3 4
HDCPEN Y Y Y Y
In 5 6 7 8
HDCPEN Y Y Y Y
Note:
1) Please disconnect all the twisted pairs before sending command EDIDUpgrade[X].
2) In above commands, “[”and “]” are symbols for easy reading and do not need to be
typed in actual operation.
3) Please remember to end the commands with the ending symbols “.” and “;”.
4) Type the command carefully, it is case-sensitive.
4.3.5 RS232 Control Modes
To control the matrix switcher, you need to connect its9 pin female RS232 port to a PC’s
RS232 port, or you can just connect any one of the HDBaseT receiver’s RS232 port with
PC (RS232 command can be transmitted to the switcher via the twisted pair). By using
RS232 control software and with right specification settings, you are able to control the
switcher.
! Control the KanexPro 8x8 Matrix Switcher from local
