KanexPro MX-HDBASE8X8-4K - GUI for TCP;IP control

4K HDBaseT™ 8x8 Matrix Switcher
MX-HDBASE8X8-4K 25
KanexPro.com
Command
Function
Feedback Example
%9966.
Check the audio sources of all outputs
Channel 1 is HDMI
Audio
Channel 2 is HDMI
Audio
Channel 3 is HDMI
Audio
Channel 4 is HDMI
Audio
Channel 5 is HDMI
Audio
Channel 6 is HDMI
Audio
Channel 7 is Analog
Audio
Channel 8 is HDMI
Audio
%9971.
Check the connection status of the inputs.
In 1 2 3 4
Connect N Y Y Y
In 5 6 7 8
Connect N Y Y Y
%9972.
Check the connection status of the
outputs.
Out 1 2 3 4
Connect N Y Y Y
Out 5 6 7 8
Connect N Y Y Y
%9973.
Check the HDCP status of the inputs.
In 1 2 3 4
HDCP N N Y Y
In 5 6 7 8
HDCP N N Y Y
%9974.
Check the HDCP status of the outputs.
Out 1 2 3 4
HDCP N N Y Y
Out 5 6 7 8
HDCP N N Y Y
%9975.
Check the I/O connection status.
Out 1 2 3 4
In 1 2 3 4
Out 5 6 7 8
In 5 6 7 8
