3 seconds to enter this mode. Dial to select
different menus, to select different options.

OUTPUTS
buttons/
EDID
Manageme
nt buttons
" Normal mode: Backlit buttons, ranging from "1" to
"8".Output 1~4 support synchronous local HDMI output.
" EDID Invoking mode: press and hold EDID button for 3
seconds or more to enter this mode, buttons 1~6
correspond to the 6 embedded EDID data separately.
Press any of the 6 buttons to invoke embedded EDID data.

Function
buttons
" ALL: Select all inputs/ outputs
Example: To transfer both AV and IR signals from input
channel No.1 to all output channels.
Operation: Press buttons in this order: “1”, “ALL”, “ENTER”
" EDID management button: Enable input port to manually
capture and learn the EDID data of output devices.
Example: Input channel No.2captures and learns the EDID
data of output channel No.4
Operation: Press buttons in this order: “EDID”, “2”, “4”,
“ENTER”
" CLEAR: Withdraw an operation like switching output
channel; learning EDID data before it comes into effect.
Meanwhile, the matrix will return to the previous status.
" ENTER: Confirm operation. Press and hold it for 3 seconds
to enter in Inquiry mode.
Notes: Pictures shown in this manual are for reference only; different model and
specifications are subject to real product.
Important:
This matrix switcher does not include any receivers, please order the receivers
separately by contacting your AV dealer or KanexPro directly. Referring part #
HDBASE70POER for optional HDBaseT receivers which are powered over Ethernet
from the Matrix switcher.
