KEB COMBIVERT F5-M / S
Name: Basis
12.05.04
Section PageDate
© KEB Antriebstechnik, 2002
All Rights reserved
Chapter
Functional DesriptionOperating and Unit Data
Adr.
min max
default
021Dh
ru.29 AN2 pre amplifier display
0,1
%
-
100-100
This parameter shows the value of analog signal AN2 in percent on the differential voltage input (terminal X2A.3 /
X2A.4) before signal amplification. In dependence on an.10 the indicated value of 0...±100 % corresponds to: 0...±10 V;
0...±20†mA or 4...20 mA (also see Chapt. 6.2 ÑAnalog inputsì).
Adr.
min max
default
021Eh
ru.30 AN2 post amplifier display
0,1
%
-
400-400
This parameter shows the value of the analog signal AN2 in percent after passing the characteristic amplifier. The range
of indication is limited to ±400 % (also see Chapt. 6.2 ÑAnalog inputsì).
Adr.
min max
default
021Fh
ru.31 AN3 pre amplifier display
0,1
%
-
100-100
This parameter shows the value of analog signal in percent on the optional input AN3 before signal amplification. In
dependence on an.10 the indicated value of 0...±100 % corresponds to: 0...±10 V; 0...±20 mA or 4...±20 mA (also see
Chapt. 6.2 ÑAnalog inputsì).
Adr.
min max
default
0220h
ru.32 AN3 post amplifier display
0,1
%
-
400-400
This parameter shows the value of the analog signal in percent on the optional input AN3 after passing the characteristic
amplifier. The range of indication is limited to ±400 % (also see Chapt. 6.2 ÑAnalog inputsì).
