KEB COMBIVERT G6 User Manual

23
PRODUCT DESCRIPTION
2.4 Part code
x x G 6 x x x - x x x x
Heat sink version
4)
0: Air-cooling
1: Flat rear
Control,
Keyboard,
Display
4)
A: G6L-G controlled without keyboard / display
B: G6L-G controlled with keyboard / display
0: G6-G controlled without keyboard / display
1: G6-G controlled with keyboard / display
2: G6P-S SCL
5)
regulated without keyboard / display
3: G6P-S SCL
5)
regulated with keyboard / display
4: G6L-M ASCL
6)
regulated without keyboard / display
5: G6L-M ASCL
6)
regulated with keyboard / display
Switching frequency;
Short time current limit;
Overcurrentcut-o󰀨
4)
5: 4 kHz / 150% / 180%
9: 4 kHz / 180% / 216%
A: 8 kHz / 180% / 216%
Voltage /
Connection type
4)
0: 1ph 230 V AC/DC
3: 3ph 400 V AC/DC
5: 3ph 400 V DC
A-Z:
Customer-/specialversion(rmware,hardware,
download)
Housing A, B, C, E
Equipment
0:
Withoutlter,withoutbrakingtransistor,without
safety
function STO
1:
Withoutlter,withbrakingtransistor,withoutsafety
function STO
3:
Internallter,withbrakingtransistor,withoutsafety
function STO
A: Like 0 with STO H:
Like A with
f=0 Hz
B: Like 1 with STO I:
Like B with
f=0 Hz
D: Like 3 with STO L:
Like D with
f=0 Hz
Control type
C: Analog / digital (standard)
D: CAN
® 2)
E: IO-Link
® 3)
F: EtherCAT
® 1)
I: VARAN
Series COMBIVERT G6
Inverter size 07…19
Table 1: Part code
continued on the next page
