31
DIMENSIONS AND WEIGHTS
3.3 Dimensions and weights
3.3.1 Built-in version
242,5
±2,5
117
100
260
M5
230
8
Housing C
Weight 4.6 kg
Dimensions All dimensions in mm
Figure 3: Built-in version with optional mounting kit
