KEB COMBIVERT G6 - Flat Rear Version; Figure 4: Flat Rear Version with Optional Mounting Kit

32
DIMENSIONS AND WEIGHTS
3.3.2 Flat rear version
242,5
±2,5
100
260
M5
117
5
175
Housing C
Weight 3.9 kg
Dimensions All dimensions in mm
Figure 4: Flat rear version with optional mounting kit
Heat-conducting paste
For information on the correct application of the heat-conducting paste visit
www.keb.de under the search term "Heat-conducting paste“.
