3 Technical Data
Unless otherwise indicated, all electrical data in the following chapter refer to a 3-phase
AC voltage supply.
3.1 Operating conditions
3.1.1 Climatic environmental conditions
Storage Standard Class Notes
Ambient temperature EN 60721-3-1 1K4 -25…55°C
Relative humidity EN 60721-3-1 1K3 5…95 % (without condensation)
Storage height – – Max. 3000 m above sea level
Transport Standard Class Notes
Ambient temperature EN 60721-3-2 2K3 -25…70°C
Relative humidity EN 60721-3-2 2K3 95%at40°C(withoutcondensation)
Operation Standard Class Notes
Ambient temperature EN 60721-3-3 3K3 5…40°C(extendedto-10…45°C)
Coolant inlet tem-
perature
Air – – 5…40°C(-10…45°C)
Liquid – – 5…40°C
Relative humidity EN 60721-3-3 3K3 5…85 % (without condensation)
Version and degree of protec-
tion
EN 60529 IP20
Protection against foreign material > ø12.5 mm
No protection against water
Non-conductive pollution, occasional conden-
sation when PDS is out of service.
Site altitude – –
Max. 2000 m above sea level
• With site altitudes over 1000 m a derating
of 1 % per 100 m must be taken into con-
sideration.
• With site altitudes over 2000 m, the control
board to the mains has only basic isola-
tion. Additional measures must be carried
out when wiring the control system.
Table 2: Climatic environmental conditions
25
