CERTIFICATION
5 Certication
5.1 CE-Marking
CE marked drive controllers are developed and manufactured to comply with the regula-
tions of the Low-Voltage Directive 2006/95/EC and EMC directive (2004/108/EC). The
harmonized standards of the series EN 61800-5-1 and EN 61800-3 were used.
5.2 Functional safety
Drive controllers with functional safety are marked with the FS logo on the nameplate.
These units are designed and manufactured in accordance with the Machine Directive
(2006/42/EC). The harmonized standard of the series EN 61800-5-2 is used.
5.3 UL Marking
Acceptance according to UL is marked at KEB drive controllers
with the adjacent logo on the nameplate.
To be conform according to UL for use on the North American and Canadian Market
the following additionally instructions must be observed (original text of the UL-File):
“During the UL evaluation, only Risk of Electrical Shock and Risk of Fire aspects were
investigated. Functional Safety aspects were not evaluated”
• “Only for use in WYE 480V/277V supply sources (or similar wording)”
• Operator and Control Board Rating of relays (30Vdc.:1A)
• "Maximum Surrounding Air Temperature 45°C"
• “Internal Overload Protection Operates prior to reaching the 180% of the Motor Full
Load Current”
• "Suitable For Use On A Circuit Capable Of Delivering Not More Than 5000 rms Sym-
metrical Amperes, 480 Volts Maximum, see instruction manual for Branch Circuit
Protection details"
and
"Suitable For Use On A Circuit Capable Of Delivering Not More Than 18000 rms
Symmetrical Amperes, 480 Volts Maximum when protected by CC, J or RK5 Class
Fuses", see instruction manual for maximum fuse sizes".
• ”Integral solid state short circuit protection does not provide branch circuit protec-
tion. Branch circuit protection must be provided in accordance with the Manufacturer
Instructions, National Electrical Code and any additional local codes”.
• Wiring Terminals marked to indicate proper connections for the power supply, load
and control circuit.
• Wiring terminals are marked to show a range of values or a nominal value of tighten-
ing torque in pound-inches to be applied to the clamping screws as shown below:
480V In/output terminals: 20.5 lb-in (2.3 Nm)
• „Use in a Pollution Degree 2 environment“
continued on the next page
