CERTIFICATION
• 480V In/output terminals:
„Use60/75°CCopperConductorsOnly,maxWireSize:8AWG,stripwireinsulationat
10 mm.
• “During the UL evaluation, only Risk of Electrical Shock and Risk of Fire aspects
were investigated. Functional Safety aspects were not evaluated”
• In order to comply with CSA C22.2 No. 14-2010 (cUL) following external Input
Chokes need to be installed: See table 1 below !
Table 1: Mains input chokes for CSA applications:
Cat. No. Housing Input Voltage [V] Reactor Cat. No. FLA Inductance [mH]
13G6 C 480 / 3ph 13DRB08–1851 3 x 16A 1.83
14G6 C 480 / 3ph 14DRB08–1451 3 x 20A 1.47
15G6 C 480 / 3ph 15DRB08-9841 3 x 30A 0.98
Branch Circuit Protection for G6 - C Drive series
I) Fuses:
Cat. No. Housing Input Voltage
[V]
Class CC, J or RK5
UL248 Fuse rating [A]
13G6 C 480 / 3ph 20
14G6 C 480 / 3ph 25
15G6 C 480 / 3ph 40
The voltage rating of the external fuses shall be at least equal to the input voltage of the
drives.
II)Listed(DIVQ,DIVQ7/CSACertied)CircuitBreakers,Type,manufacturerandelec-
tricalratingsasspeciedbelow:
Cat. No. Housing Type Manufacturer Ratings
13G6 C 5SJ4 320-8HG42
S203UP-K 20
FAZ D20/3-NA
1489 A3D 200
Siemens
ABB
Eaton
Allen Bradley
480Y/277V, 20A
14G6 C 5SJ4 325-8HG42
S203UP-K 25
FAZ D25/3-NA
1489 A3D 250
Siemens
ABB
Eaton
Allen Bradley
480Y/277V, 25A
15G6 C N/A N/A N/A
III)Listed(NKHJ,NKHJ7/CSACertied)TypeESelfProtectedManualMotorControl-
lers,Typeandmanufacturerandelectricalratingsasspeciedbelow:
Cat.
No.
Housing Self Protected
Manual Motor Con-
troller,
Type
Manufac-
turer
Self Protected
Manual Motor
Controller,
ratings
Dial set-
ting
[A]
13G6 C PKZM0(1) 25-E Eaton 480Y/277V, 15.0 Hp 25
14G6 C PKZM0(1) 25-E Eaton 480Y/277V, 15.0 Hp 25
15G6 C PKZM0(1) 32-E Eaton 480Y/277V, 20.0 Hp 32
