Page 3.8 - 6 COMBIVERT R6-S © KEB, 2008-02
Special functions
Timer reset condition (LE.20 / LE.25)
The conditions when the timerisresetadditionallytotheinputscanbedenedinaccordancewiththefollowing
table. The individual conditions are OR-operated.
Bit No. Decimal value condition
0 1 Modulation on
1 2 Modulation off
2 4 reserved
3 8 Change of parameter set
4 16 Power-On-Reset
Comparison level 0...7 (LE.00...LE.07)
LE.00...LE.07denethelevel for the switching conditions 37 / 38 („timer > level“). If the timer exceeds the
adjusted value the switching condition is set. A level in the range of -10.737.418,24 to 10.737.418,23 can be
adjusted. But only values of 0...655,35 are sensible for the counter.
