Seite 3.6 - 4 COMBIVERT R6-S © KEB, 2008-02

Protective functions

Unity of the pre-warning

Pre-warning period or level adjustable

Pre-warning possible via digital output

Function can be switched off

Automatic restart adjustable

Error without adjustable response

Message

Operator

Value Message COMBIVIS

E.buS/ A.buS 18/93 Error!/warning! watchdog - • • - • s

E.dOH/ A.dOH 9/96 Error!/warning! temperature of the commutation choke - • • • • s

E.EEP 21 Error! EEPROM defective • - - - - -

E.EF/ A.EF 31/90 Error!/warning! ERROR external fault - • • - - -

E.LSF 15 Error! load shunt fault • - - - - -

E.nEt 3 Error! Net • - - - - -

E.OC 4 Error! overcurrent - • - - - -

E.OH/ A.OH 8/89 Error!/warning! Power module temperature - • - • • °C

E.OHI/ A.OHI 6/87 Error!/warning! interior temperature - • • • • s

E.OL/ A.OL 16/99 Error!/warning! overload (Ixt) - • - • • %

E.OP 1 Error! overvoltage - • - - - -

E.PU 12 Error! defective in power unit • - - - - -

E.Puch 50 Error! power unit code changed • - - - - -

E.PucI 49 Error! power circuit unknown • - - - - -

E.PUIN 14 Error! power unit coding • - - - - -

E.SEt/ A.SEt 39/102 Error!/warning! set - • • - - -

E.SYn 59 Error! synchronization • - - - - -

E.UP 2 Error! underpotential - • - - - -

F.nEt 40 Error! mains frequency • - - - - -

3.6.1.1 Undervoltage

„Error! Undervoltage“ (E.UP) is triggered if the DC link voltage drops due to brownouts or a generally too weak

power grid. For this error, the automatic restart can be activated.

3.6.1.2 Overvoltage

„Error! Overvoltage“ is triggered if the DC link voltage increases beyond the overvoltage level.

3.6.1.3 Overcurrent

The „Error! Overcurrent“ (E.OC) is triggered, if the „OC tripping current“ (see technical data in the instruction

manual) is exceeded.

If this error occurs permanently, either the parameter setting is not correct or the COMBIVERT is defective.

KEB combivert R6-S Applications Manual
