2.1.4 ENTER parameters
For some parameters it is not reasonable that the selected values are immediately active. They are called
ENTERparameters,becausetheybecomeactiveonlyafterconrmingwiththeENTERkey.
2.1.5 Not set-programmable parameters
Certain parameters are not set-programmable, since their value must be the same in all sets (e.g. bus address
orbaudrate).Theparametersetnumberismissingintheparameteridenticationinorderthattheseparame-
ters are immediately visible.
Always the same value is valid for all non set-programmable parameters independent of the selected
parameter set!
2.1.6 Reset of error messages
Ifamalfunctionoccursduringoperation,thentheactualdisplayisoverwrittenbyaashingalarmmessage.
The error message can be deleted by pressing the ENTER key, so the original value is displayed again.
Attention! Resetting the error message with ENTER is not an error reset, i.e. the error status in the inverter
is not reset. Thus it is possible to change adjustments before the error reset. An error reset is only possible by
reset terminal or control release.
2.1.7 Reset of peak values
There are parameters which display the peak values to draw conclusions from the operational performance of
a drive. Peak value means the highest measured value is stored for the ON time of the inverter (slave pointer
principle).Thepeakvalueisdeletedandtheactualmeasuredvalueisdisplayedbypressing▲or▼.
2.1.8 Acknowledge of feedbacks
Some parameters send a feedback in order to monitor the proper operation. Par example, the display "PASS"
indicates after copying a set, that the operation was completed error free. These feedbacks must be accepted
with ENTER.
