Start-up

4.2 Start-up

After all preparatory measures have been carried out and checked the KEB COMBIVERT can be switched

on.

All control releases ST(X2A.12)mustbedeactivatedwhenswitchingonthersttime, since the COMBIVERT

R6-Sisnotcustom-specicparameterized.

The following descriptions suppose that the COMBIVERT is on the password level "application mode" (ud.01

= application mode). The selection of the password level is described in the manual chapter 2.2. The start-up

should be executed with COMBIVIS in order to have a short start-up time.

Operating lists are available on the KEB homepage (www.keb.de). This lists contain the necessary parameters

for start-up.

Attention:Thestart-upinstructionmanualcanonlygiveashortoverviewoftheparameteradjustmentswhich

are mandatory necessary to start-up the COMBIVERT.

Thus it represents a check list and not a complete parameter description.

The appropriate chapters of the application manual must be read carefully for exact information about the pa-

rameters,additionallypointstoconsiderandapplication-specicadjustments!

The units are not short-circuit proof without corresponding dimensioned fuses!

Exceeding of the max. rechargeable DC link capacity can lead to a defect!

A load removal in the DC link circle may be done only after the message „ready“!

The wiring must be checked before start-up, particularly the wiring of the control release of the connected inver-

ters (see page 1.3-8). No parameterizations are needed for power supply operation. A vew parameter settings

are necessary only for regenerative operation.

4.2.1 R6-S operation power supply and regenerative unit

No parameter settings are necessary in the operating mode as power supply and regenerative unit when

usingaR6-SunitandKEBcommutationchokeorharmoniclterbasedondefaultsettingsandPn.19 (CP.33).

Pn.19 Operating mode

TheparameterdeneswhethertherespectiveR6unitisoperatedasmasterorslave,withcommutationchoke

orharmoniclter.

With parameterization of Pn.19 (CP.33), cS.00 and cS.01 (data commutation choke) as well as cS.04 (control

angle) are preset for the actual R6 unit (reference to the power unit code) and the appropriate choke or har-

moniclter.

Choke rating data

cS.00 Choke/rated voltage, cS.01 Data commutation choke

Setting in accordance with the data sheet of the choke.

Parameters are preset with Pn.19 (CP.33). Only relevant for special chokes!
