Page 3.2 - 10 COMBIVERT R6-S © KEB, 2008-02

Operating and appliance data

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.39 OL counter display 0227h ro - - 0 100 1 % -

In order to prevent „E.OL“ - errors by overload (load reduction in due time), the internal count of the OL

counter can be made visible with this display. At 100% the COMBIVERT switches off with error „E.OL“. The

error can be reset only after a cooling time (blinking display „E.nOL“).

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.40 Power on counter 0228h rw - - 0 65535 1 h -

The power on counter displays the time the inverter was switched on. The displayed value comprises all

operating phases. On reaching the maximum value (approx. 7.5 years) the indication remains on the maxi-

mum value.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.41 Modulation on counter 0229h rw - - 0 65535 1 h -

The modulation on counter displays the time the COMBIVERT was active (power modules controlled). On

reaching the maximum value (approx. 7.5 years) the indication remains on the maximum value.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.43 Timer 1 display 022Bh rw - - 0 655,35 0,01 - -

The count of the free-programmable timer 1 is displayed. The display is done either in seconds, in hours

or in slopes/ 100 (see LE.21). The counter can be adjusted to any chosen value by keyboard or bus. The

programming of the counter is done with parameters LE.17...LE.21.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.44 Timer 2 display 022Ch rw - - 0 655,35 0,01 - -

The count of the free-programmable timer 2 is displayed. The display is done either in seconds, in hours

or in slopes/100 (see LE.26). The counter can be adjusted to any chosen value by keyboard or bus. The

programming of the counter is done with parameters LE.22...LE.26.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.46 External temperature 022Eh ro - - 0 255 1 - -

Overtemperature switch of the commutation throttle. Precondition for this function is a special power circuit.

The temperature detection is connected to the terminals T1/T2.

0: T1/T2closed   252: powerunitnotready

255: T1/T2open

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.68 Rated DC voltage 0244h ro - - 0 1000 1 V -

This parameter displays the rated DC voltage automatically determined by the inverter. The value is measured

at switch-on.
