Operating and appliance data
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
In.25 Error diagnosis 0E19h ro + - 0 65535 1 - 0
Shows the last errors that occurred (in the sets 0...7). The oldest error is in set 7. A new error is stored in
set 0. All other errors are shifted to the next parameter. The oldest error is not applicable. The display of the
error occurs in the highest word (Bit 12…15).
A difference time is determined between errors of the same type (e.g. double OC). This time is stored in the
three low-order words. The display occurs in hexadecimal code.
Error Difference time
ValueBit Bit Bit Bit
15…12 11…8 7…4 3…0
X 0 0 0 0 min.
X 0 0 1 1 min.
X : : : :
X F F E 4094 min.
X F F F > 4095 min.
0 X X X no error
1 X X X E.OC
2 X X X E.OL
3 X X X E.OP
4 X X X E.OH
5 X X X E.OHI
Example: The following values are displayed:
Set0: 3000
Set1: 2000
Set2: 4023
Set3: 4000
Set4-7: 0000
Explanati-
on:
The error that occurs last is stored in set 0. In the table the highest hex-value „3“ indicates
error E.OP (overvoltage).
Before it error E.OL (set 1=2xxx) occurs. Since the errors are of different types, no difference
time was stored.
Error E.OH is stored in set 2 and 3. Since the errors are of the same type, a diffenrence time
(here „023 “) is stored in the three low-order words of set 2. The value of 23 hexadecimal
corresponds decimal to a difference time of 35 minutes.
No errors are stored in set 4…7.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
In.26 E.OC error counter 0E1Ah
rw - - 0 65535 1 - 0
In.27 E.OL error counter 0E1Bh
In.28 E.OP error counter 0E1Ch
In.29 E.OH error counter 0E1Dh
In.30 E.OHI error counter 0E1Eh
The error counters (for E.OC, E.OL, E.OP, E.OH, E.OHI) specify the total number of errors of each error
type.
