KEB combivert R6-S Applications Manual

Seite 3.4 - 14 COMBIVERT R6-S © KEB, 2008-02
Digital in- and outputs
do.00...do.07: Conditions
Value Function Description
59 Inputs AND linked (ru.22)
Function Conditionmetwhen:
AND all selected inputs active
OR at least one selected input active
NAND at least one selected input inactive
NOR all selected inputs inactive
The selection of inputs to be linked is made by the comparison level parame-
ters LE.00...LE.07.
Input ST RST F R I1 I2 I3 I4 IA IB IC ID
Value 1 2 4 8 16 32 64 128 256 512 1024 2048
The sum of the inputs to query is entered in the switching levels.
Example:IfconditionF,RandI1shallbelinkedtocondition0,value4+8+
16 = 28 must be entered in LE.00.
60 Inputs OR linked (ru.22)
61 Inputs NAND linked (ru.22)
62 Inputs NOR linked (ru.22)
63
Absolute value ANOUT1 >
level
Value of ANOUT1 (amount of ru.34 „ANOUT1 post ampl. display) higher than
the switching level.
65 ANOUT1 > level
ANOUT1 (ru.34 „ANOUT1 post ampl. display) higher than the switching le-
vel.
73 Value actual power > level Value ru.81 „actual power“ > switching level
74 Actual power > level ru.81 „actual power“ > switching level
80 AC input current > level
Not listed values are not assigned.
Comparison level 0...7, LE.00...LE.07
Theseparametersdenetheswitchinglevelsofthedifferentconditions.
Switching level 0 is valid for switching condition 0, switching level 1 is valid for switching condition 1... etc.
Hysteresis 0...7, LE. 08...LE.15
The hysteresis referring to the adjusted values determine parameters LE.08...LE.15.
Hysteresis 0 (LE.08) is valid for switching level 0; LE.09 for switching level 1... etc.
