Keithley 2302 User Manual

Getting Started 1-5
Figure 1-2
Model 2306-VS dual channel battery/charger simulator
A
) Front Panel
B) Rear Panel
WARNING:NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
CAUTION:FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
MADE IN
U.S.A.
LINE RATING
100-120VAC,
200-240VAC
50, 60 HZ
165VA MAX.
LINE FUSE
SLOWBLOW
2.0A, 250V
IEEE-488
+++
____
+
DVM IN
OUTPUT #2
SOURCE SENSE SOURCE
+++
____
+
DVM IN
OUTPUT #1
SOURCE SENSE SOURCE
ISOLATION FROM EARTH: 22 VOLTS MAX.
DVM IN
+30 VDC MAX.
TRIGGER
CAT I
IN OUT IN OUT
CHANNEL 1 CHANNEL 2
POWER
DISPLAY
OPERATE
ENTER
SET
MENU
LOCAL
2306-VS DUAL CHANNEL BATTERY/CHARGER SIMULATOR
NOTE The output from each channel is isolated from the other channel.
Make sure that the maximum combined channel output is n
ot exceeded (see Specifications in
Appendix A). Also, do not exceed 3A when using the power supply as a sink. For output volt-
ages exceeding 5V, the maximum sink current is less than 3A (derate the maximum sink current
0.
2A for each volt over 5V).
