Table 16-3
Model 2306 display board parts list
Circuit designation Description Keithley part no.
C601,C602 CAP, 33PF, 10%, 100V, CERAMIC C-451-33P
C603,C616 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C609 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C611 CAP, 10UF, 20%, 25V, TANTALUM C-440-10
C613 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C614,C615 CAP, 390P, 10%, 100V, CERAMIC C-451-390P
J1008 CONN, HEADER STRAIGHT SOLDER
PIN
CS-368-10
J1013 CONNECTOR, RIGHT ANGLE CS-362
J1014 CONN, BERG CS-339
L601,L602,L603,L604 FERRITE CHIP 600 OHM, BLM32A07 CH-62
R601 RES, 10M, 5%, 125MW, METAL FILM R-375-10M
R602-605,611,614,616,618,620,623 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R606,608,610,613,615,617,619,621 RES, 15k, 1%, 100MW, THICK FILM R-418-15K
R607 RES, 1.07K, 1%, 100MW, THIN FILM R-438-1.07K
R612 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R622 RES, 15k, 1%, 100MW, THICK FILM R-418-15K
RV601,RV602 300W TRANSIENT VOLTAGE
SUPPRESSOR ARRAY
VR-13
SO601 SOCKET SO-143-44
U601 UNDERVOLTAGE SENSE CIRCUIT IC-1067
U603, DISP BRD PROGRAMMED ROM 2306-800B01
U604 INTEGRATED CIRCUIT SMT IC-1305
Y601 CRYSTAL, 4MHZ CR-36-4M
VACUUM FLUORESCENT DISPLA
Y DD-60
16-14 Replaceable Parts
