Keithley 2302 User Manual

Table B-2
Error and status messages (Model 2306-VS only)
Number Description Event
+220
+221
+222
+223
+224
+225
+226
+227
+228
+229
+230
+231
+232
+233
+234
+235
+236
+237
Channel enabled with both conflict
Opposite channel enabled with both conflict
Channel step read and step volt conflict
Channel step read and function conflict
Trigger external enable init conflict
Bothtrigext command on parameter conflict
Bothon parameter with a channel both conflict
Both volt has step volt or step read conflict
Both auto has step volt or step read conflict
Channel one and two have step points conflict
Parameter with both set to none conflict
Parameter with both not set to none conflict
Both volt with a step volt or read conflict
Both auto with a step volt or read conflict
Trigger external setting channel enabled conflict
Trigger external enabled system setting conflict
Trigger continuous and external enable conflict
Trigger external enable long integration conflict
EE
EE
EE
EE
EE
EE
EE
EE
EE
EE
EE
EE
EE
EE
EE*
EE**
EE
EE
EE = error event
**If
TRIG:EXT:ENAB:OFF is sent while channels BOTH = VOLT or AUTO, or the other
channel has BOTH set to VOLT/AUTO with external trigger enabled, an error +234 will be
generated. In this case, use BOTHTRGEXT to disable.
**Error +235 generated for these comma
nds if external trigger enabled:
*TRG, *TRG1, *TRG2
READ1?, READ2?
MEAS?
BOTHREAD?
BOTHFETCh?
BOTHTRG
See Section 9 and Section 10.
