Keysight B1500A Configuration and Connection Guide
2-15
B1500A Accessories
Accessories for the B1500A
N1254A-302 Mini banana - pin plug (red, 1 ea) Mini banana - pin plug included
in 16442B-811
N1254A-303 Mini banana - pin plug (blue, 1 ea) Mini banana - pin plug included
in 16442B-811
N1254A-304 Pin plug - pin plug (black, 1 ea) Pin plug - pin plug included in
16442B-812
N1254A-305 Pin plug - pin plug (red, 1 ea) Pin plug - pin plug included in
16442B-812
N1254A-306 Pin plug - pin plug (blue, 1 ea) Pin plug - pin plug included in
16442B-812
N1254A-307 Mini banana - mini clip (black, 1 ea) Mini banana - mini clip included
in 16442B-813
N1254A-308 Mini banana - mini clip (red, 1 ea) Mini banana - mini clip included
in 16442B-813
N1254A-309 Mini banana - mini clip (blue, 1 ea) Mini banana - mini clip included
in 16442B-813
N1254A-310 Mini banana - mini banana (black, 1 ea) Mini banana - mini banana
included in 16442B-814
N1254A-311 Mini banana - mini banana (red, 1 ea) Mini banana - mini banana
included in 16442B-814
N1254A-312 Mini banana - mini banana (blue, 1 ea) Mini banana - mini banana
included in 16442B-814
Accessories
N1254A-400 Coaxial cable between connector plate and probe
card, black 1 m
Coaxial cable (50 ohm) between
connector plate and probe card,
black 1 m
N1254A-401 Triaxial connector for SMU and HCU (female)
N1254A-402 Interlock micro switch (3101-0302)
Accessories for B1505A
N1254A-500 HV jack connector panel mount - Solder type This option is available for
accessories on the Keysight
B1505A Power Device
Analyzer/Curve Tracer. For
details, please refer to the Product
Guide of B1505A.
N1254A-501 HV jack to jack adapter
N1254A-502 HV plug connector panel mount - Solder type
N1254A-503 HCSMU coaxial cable assy 1.5 m - BNC to
open-end
N1254A-504 HVSMU jack cable assy 1.5 m - HV jack to
open-end
Model/Option Description Additional Information
To Next Page
