2-16
Keysight B1500A Configuration and Connection Guide
B1500A Accessories
Accessories for the B1500A
N1254A-505 HVSMU triaxial cable assy 1.5 m - HV plug to
open-end
This option is available for
accessories on the Keysight
B1505A Power Device
Analyzer/Curve Tracer. For
details, please refer to the Product
Guide of B1505A.
N1254A-506 HVSMU coaxial cable assy 1.5 m - HV plug to
open-end
N1254A-507 HVSMU coaxial cable assy 1.5 m - HV plug to HV
plug
N1254A-508 Connection wire, red 1 ea
N1254A-509 Connection wire, black 1 ea
N1254A-510 Dolphin clip adapter, black 1 ea and red 1 ea.
N1254A-511 Cable lag adapter, black 1 ea and red 1 ea.
N1254A-512 SHV cable, 250 mm
N1254A-513 SHV to banana adapter, 1ea
N1254A-514 BNC (m) to BNC (m) adapter, 1 ea
N1254A-515 BNC (f) - BNC (m) - BNC (f) adapter, 1 ea
N1254A-516 BNC (f) - BNC (f) - BNC (f) adapter, 1 ea
N1254A-517 Adapter, Triaxial Jack to Triaxial Plug, 1 ea
N1254A-518 SHV Cable 1.5 m
N1254A-520 10 kV Ultra High Voltage Open End Cable, 1 m
N1254A-521 10 kV Ultra High Voltage Jack to Jack Adapter
N1254A-522 1500 A Ultra High Current Banana to Banana Cable,
2 ea.
N1254A-523 1500 A Ultra High Current Banana to Open End
Cable, 1 m, 2 ea
N1254A-524 500 A Ultra High Current Prober System Cable
N1254A-525 SHV Cable Assy 1.5m - SHV Plug To Open-end
N1254A-526 Ultra High Current Cable, 2m, No Connectors At
Either End
N1254A-527 PTFE Standoff, Jack, 4 ea.
N1254A-528 PTFE Standoff With Banana Plug, 4 ea.
N1254A-550 Test Leads And Connection Kit
For Thermal Test, 20 cm
N1254A-551 Test Leads And Connection Kit
For Thermal Test, 30 cm
Model/Option Description Additional Information
To Next Page
