B1500A Accessories
Accessories for the wafer prober / connector plate
Table 2-10 Item number information of 16495G Connector Plate with 24 Triaxial, Interlock and
GNDU connectors
Table 2-11 Item number information of 16495H Connector Plate with 6 Triax., 6 BNC, Intlk,
GNDU
Table 2-12 Item number information of 16495J Connector Plate with 8 Triax., 4 BNC, Intlk,
GNDU
Item. Description OP Instruction
16495G Connector plate with 24
triaxial, interlock and
GNDU connectors
Full size connector plate with 24 triaxial, interlock and
ground unit connectors. Common terminals are connected
to plate.
ATTENTION: Must specify either 16495G-001 or
16495G-002
16495G-001 Bulkhead feedthru
connectors
Connection type is "Connector-Connector"
16495G-002 Connectors to contacts for
soldering
Connection type is "Connector-Solder"
Item. Description OP Instruction
16495H Connector plate with 6
triax., 6 BNC, intlk,
GNDU
Half size connector plate with 6 triaxial, 6 BNC, interlock
and ground unit connectors. Common terminals are
floating.
ATTENTION: Must specify either 16495H-001 or
16495H-002
16495H-001 Bulkhead feedthru
connectors
Connection type is "Connector-Connector"
16495H-002 Connectors to contacts for
soldering
Connection type is "Connector-Solder"
Item. Description OP Instruction
16495J Connector plate with 8
triax., 4 BNC, intlk,
GNDU
Half size connector plate with 8 triaxial, 4 BNC, interlock
and ground unit connectors. Common terminals are
floating.
ATTENTION: Must specify either 16495J-001 or
16495J-002
16495J-001 Bulkhead feedthru
connectors
Connection type is "Connector-Connector"
16495J-002 Connectors to contacts for
soldering
Connection type is "Connector-Solder"
