Keysight Technologies N5221A

6-10 Keysight N5221A/22A Service Guide
Replaceable Parts
Replaceable Parts Listings
6-
Front Panel Assembly, Front Side, All Options
The N5245-60024 (Was N5247-60004) 2-port front panel assembly and
the N5245-60022 (Was N5247-60005) 4-port front panel assembly
contain the items shown in the following table.
Reference
Designator
Part Number Qty Description
➀
N5247-20137
1
Front frame, 2-port (frame only, not the assembly)
N5247-20141 Front frame, 4-port (frame only, not the assembly)
8160-0660 1.2 m RFI gasket material, 1.2 meters in length
(Must be ordered separately from front frame.)
0515-2044 20 Machine screw (x12), M4.0 x 12 flat head (To attach front frame to chassis.)
Machine screw (x8), M4.0 x 12 flat head (To attach front handles to front
panel.) Note: Front handle screws not shown.
a
a. Refer to “Rack Mount Kits and Handle Kits” on page 6-106 for part numbers of complete rack mount kits.
5041-9176 2 Trim strip, filler (For analyzers without handles.)
N5242-80005 1 Keypad overlay
N5222-80002 1 Lower front panel overlay, 2-port (Option 200)
N5222-80003 Lower front panel overlay, 2-port (Option 201)
N5227-80002 Lower front panel overlay, 2-port (Option 210)
N5222-80004 Lower front panel overlay, 2-port (Option 217)
N5222-80003 Lower front panel overlay, 2-port (Option 219)
N5222-80005 Lower front panel overlay, 4-port (Option 400)
N5222-80006 Lower front panel overlay, 4-port (Option 401)
N5227-80003 Lower front panel overlay, 4-port (Option 410)
N5222-80007 Lower front panel overlay, 4-port (Option 417)
N5222-80006 Lower front panel overlay, 4-port (Option 419)
N5242-80007 1 Power switch overlay
W1312-40017 1 Front panel (RPG) knob
N5221-80005 1 Nameplate, N5221A
N5222-80001 Nameplate, N5222A
0515-1946 4 Machine screw, M3.0 x 6, 90-deg flat head (To attach subpanel to front
frame.) (Only 2 used on 2-port, all 4 used on 4-port.)
2
3
4
5
6
7
8
9
