Keysight N5221A/22A Service Guide 6-101
Replaceable Parts
Replaceable Parts Listings
Internal Hardware and Miscellaneous Parts, All Options
Reference
Designator
Part Number Qty Description
N5221-00003 1 Left side inner bracket
W1312-00048 1 Midplane bracket
N5221-00002 1 Right side inner bracket
N5242-00001 1 Chassis
0515-0372 39 Machine screw, M3.0 x 8, pan head (4 to attach midplane bracket to left
and right side inner brackets, 6 to attach front bracket to left and right side
inner brackets, 2 to attach side bracket to front bracket, 5 to attach side
bracket to chassis, 22 to attach chassis to left and right side inner
brackets, midplane bracket, and front bracket.)
N5242-00017 1 Front bracket
N5242-40002 16 PC board guides
N5242-00016 1 Side bracket (left)
