Replaceable Parts
Replaceable Parts Listings
6-
Rear Panel Assembly, All Options
Item
Number
Part
Number
Qty Description
A17 CPU board. Refer to “Top Assemblies and Cables, All Options” on page 6-16 for part number.
A51 Solid state drive assembly (SSDA). Refer to “Top Assemblies and Cables, All Options” on
page 6-16 for A51 part numbers.
N5245-00028 Power supply rear panel
0515-0372 28 Machine screw, M3.0 x 8, pan head
Rear foot and screw (Refer to “External Hardware and Miscellaneous Parts, All Options” on
page 6-103.)
6960-0149 1 Hole plug
N5242-00010 1 Rear panel
2190-0958
Was 2190-0034
-- Lock washer
0380-0644 -- Jack screw
2190-0584 -- Lock washer
0380-4670 -- Jack screw, 0.442 inch length
1251-7812 -- Jack screw, 0.5 inch length
N5242-60005 1 PWR I/O cable assembly
1250-4261
Was: 1810-0118
2 Termination, 50 ohm load
8121-0834 1 HANDLER I/O cable assembly
2190-0068 -- Lock washer
2950-0054 -- Hex nut
Bottom foot (Refer to “External Hardware and Miscellaneous Parts, All Options” on
page 6-103.)
6960-0076 9 Hole plug
2190-0102 -- Lock washer
2950-0035 -- Hex nut
1250-3805 2 Bulkhead connector, f-f, PC 3.5, 50-ohm; includes hex nut and washer
3050-2330 -- Lock washer (For A24 IF MUX board connectors.)
2950-0414 -- Hex nut (For A24 IF MUX board connectors.)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
