6-12 Keysight N5221A/22A Service Guide
Replaceable Parts
Replaceable Parts Listings
6-
Front Panel Assembly, Back Side, All Options
Reference
Designator
Part Number Qty Description
A1 N5240-60065
Was N5240-60046
1 Front panel interface board
A2 N5240-60063
Was N5240-60047
1USB board
not shown N5242-60010 1 Ribbon cable, 60-wire, A14 system motherboard J9 to A1 front panel
interface board J1
➀
N5242-40001 1 Keypad assembly
➁
0515-0430 12 Machine screw, M3.0 x 6 pan head (9 to attach front panel interface board
to front frame and 3 to attach display cable to display hold down bracket.)
➂
N5242-40009
Was N5242-40003
1 Touch screen rubber boot
➃
2090-1045
Was 2090-0973
1 Touch screen, 10.4 inch
➄
0515-0372 16 Machine screw, M3.0 x 8 pan head (6 to attach display to front frame, 6 to
attach LCD display assy to bracket, and 4 to attach USB board to front
frame.)
➅
E6601-61028 1 Cable, A3 front panel interface board to inverter board
➆
0515-1934 4 Machine screw, M2.5 x 6 pan head (To attach inverter board and USB
controller board to display hold down bracket.)
➇
a
critical footnote
0950-5396 (LED) 1 Inverter board
0950-4420 (Tube)
➈
0960-3063
Was 0960-2804
1 Touch screen controller board
0515-1521 2 Machine screw, M3.0 x 5 flat head (To attach power switch assembly to
front frame.)
N5240-60064
Was N5240-60050
1 Power switch board
N5240-40001 1 Power button keypad
W1312-60047
Was 8121-1452
1 Touch screen controller board cable harness
8121-1451 1 Power switch cable harness
1400-0510 2 Cable clamp (with adhesive backing)
0515-0667 1 Machine screw, M3.0 x 25 pan head (To attach display to front frame.)
