Keysight Technologies N5221A

6-32 Keysight N5221A/22A Service Guide
Replaceable Parts
Replaceable Parts Listings
6-
Bottom Ribbon Cables and Wire Harnesses, 2-Port, Option 201
Reference
Designator
Type
a
Part Number Description
3W N5242-60009 A19 test set motherboard J221 to port 1 LED board J1
4W N5242-60002 A19 test set motherboard J3 to A33 reference mixer switch
10R N5242-60005 Rear-panel PWR I/O to A19 test set motherboard J301
16R N5242-60006 A19 test set motherboard J212 to A23 mixer brick (1)
3W N5242-60009 A19 test set motherboard J222 to port 2 LED board J1
24R N5230-60014
Was N5242-60011
A19 test set motherboard J209 to A21 HMA26.5
100R N5242-60004 A14 system motherboard J1 to A19 test set motherboard J1 to
A20 IF multiplexer board J1
36R 8121-0834 Rear-panel HANDLER I/O to A19 test set motherboard J400
a. nR = n wires in a ribbon (flat) cable; nW = n wires in a wire harness
1
2
3
4
5
6
7
8
