Keysight Technologies N5221A

Keysight N5221A/22A Service Guide 6-45
Replaceable Parts
Replaceable Parts Listings
Bottom Ribbon Cables and Wire Harnesses, 2-Port, Option 217
Reference
Designator
Type
a
Part Number Description
3W N5242-60009 A19 test set motherboard J221 to port 1 LED board J1
4W N5242-60002 A19 test set motherboard J3 to A33 reference mixer switch
10R N5242-60005 Rear-panel PWR I/O to A19 test set motherboard J301
14R N5242-60008 A19 test set motherboard J201 to A34 port 1 source attenuator
10R 8121-0982
Was N5242-60007
A19 test set motherboard J205 to A42 port 1 receiver attenuator
16R N5242-60006 A19 test set motherboard J212 to A23 mixer brick (1)
3W N5242-60009 A19 test set motherboard J222 to port 2 LED board J1
10R 8121-0982
Was N5242-60007
A19 test set motherboard J208 to A45 port 2 receiver attenuator
14R N5242-60008 A19 test set motherboard J204 to A37 port 2 source attenuator
24R N5230-60014
Was N5242-60011
A19 test set motherboard J209 to A21 HMA26.5
100R N5242-60004 A14 system motherboard J1 to A19 test set motherboard J1 to
A20 IF multiplexer board J1
36R 8121-0834 Rear-panel HANDLER I/O to A19 test set motherboard J400
a. nR = n wires in a ribbon (flat) cable; nW = n wires in a wire harness
