Keysight Technologies N5221A

Keysight N5221A/22A Service Guide 6-99
Replaceable Parts
Replaceable Parts Listings
N5227-00001 1 Test set front sub panel, 2-port models without front panel jumpers
N5221-00006 Test set front sub panel, 2-port models with front panel jumpers
N5221-00007 1 Test set front sub panel, all 4-port models
N5242-00005 1 Bracket (For A21 HMA26.5.)
N5242-00019 1 Stabilizer bracket (Between A19 test set motherboard and A20 IF mux board.)
1250-4261
Was: 1810-0118
2 Termination, 50-ohm load (For J6 and J7.)
0515-0669 4 Machine screw, M4.0 x 0.7, pan head (To attach A20 IF MUX to test set deck.
1250-3805 12-
24
Bulkhead connector, f-f, PC 3.5, 50-ohm; includes hex nut and washer (Qty 12 for
options 201, 217, and 219; qty 24 for options 401, 417, and 419.)
N5235-00018 1 Bracket, ribbon cable clamp
Reference
Designator
Part Number Qty Description
17
18
19
20
21
22
23
