7-16 Keysight N5221A/22A Service Guide
Repair and Replacement Procedures
Removing and Replacing the A4–A13 Boards
7-
2. Perform the post-repair adjustments, verifications, and performance tests
that pertain to this removal procedure. Refer to Table 7-2 on page 7-60.
The A4, A11, and A13 synthesizer boards will not perform correctly and
will cause the PNA to display errors until the Synthesizer Bandwidth
Adjustment and the EE Default Adjustment are completed, as per Table
7-2 on page 7-60
.
