STATus:OPERation:CONDition?
Queries the condition register for the Operation Status group. This is a read-only register, which holds
the live (unlatched) operational status of the instrument. Reading the Operation Status Condition
register does not clear it.
Parameter Typical Return
(none) <bitvalue>
Read the operation status condition register: STAT:OPER:COND?
l The value returned is the binary-weighted sum of all bits set in the register. For example, with bit
3 (value 8) and bit 5 (value 32) set (and corresponding bits enabled), the query returns +40.
l The condition register bits reflect the current condition. If a condition goes away, the cor-
responding bit is cleared.
l *RST clears this register, other than those bits where the condition still exists after *RST.
STATus:OPERation:ENABle <value>
STATus:OPERation:ENABle?
Sets the value of the enable register for the Operation Status group. The enable register is a mask for
enabling specific bits from the Operation Event register to set the OPER (operation summary) bit of the
Status Byte register.STATus:PRESet clears all bits in the enable register.
Parameter Typical Return
A decimal value corresponding to the binary-weighted sum of
the register's bits.
<bitvalue>
Enable bit3 and 4 in the enable register: STAT:OPER:ENAB 24
l For example, with bit 3 (value 8) and bit 5 (value 32) set (and corresponding bits enabled), the
query returns +40.
l *CLS does not clear the enable register, but does clear the event register.
STATus:OPERation:NTRansition <value>
STATus:OPERation:NTRansition?
STATus:OPERation:PTRansition <value>
STATus:OPERation:PTRansition?
Sets and queries the value of the NTR (Negative-Transition) and PTR (Positive-Transition) registers.
These registers serve as a polarity filter between the Operation Condition and Operation Event
registers.
When a bit in the NTR register is set to 1, then a 1-to-0 transition of the corresponding bit in the
Operation Condition register causes that bit in the Operation Event register to be set.
6 SCPI Programming Reference
265 Keysight N6900/N7900 Series Operating and Service Guide
