When a bit in the PTR register is set to 1, then a 0-to-1 transition of the corresponding bit in the
Operation Condition register causes that bit in the Operation Event register to be set.
STATus:PRESet sets all bits in the PTR registers and clears all bits in the NTR registers.
Parameter Typical Return
A decimal value corresponding to the binary-weighted sum of
the register's bits.
<bitvalue>
Enable bit3 and 4 in the NTR register: STAT:OPER:NTR 24
Enable bit3 and 4 in the PTR register: STAT:OPER:PTR 24
l If the same bits in both NTR and PTR registers are set to 1, then any transition of that bit at the
Operation Condition register sets the corresponding bit in the Operation Event register.
l If the same bits in both NTR and PTR registers are set to 0, then no transition of that bit at the Oper-
ation Condition register can set the corresponding bit in the Operation Event register.
l The value returned is the binary-weighted sum of all bits set in the register.
STATus:OPERation:USER<1|2>:SOURce EXPRession<1-8>|NONE
STATus:OPERation:USER<1|2>:SOURce?
Maps the specified expression to one of the two user-defined Operation Status bits (USER1 or USER2).
When the specified expression is true, the selected user status bit will be set.
Parameter Typical Return
EXPRession<1-8>|NONE *RST NONE EXPR<1-8>
Maps a user-defined status bitto an expression:
STAT:OPER:USER1:SOUR EXPR1
STATus:PRESet
Presets all Enable, PTR, and NTR registers.
Operation register Questionable register Presetsetting
STAT:OPER:ENAB STAT:QUES<1|2>:ENAB all defined bits are disabled
STAT:OPER:NTR STAT:QUES<1|2>:NTR all defined bits are disabled
STAT:OPER:PTR STAT:QUES<1|2>:PTR all defined bits are enabled
Parameter Typical Return
(none) (none)
Presetthe Operation and Questionable registers: STAT:PRES
Keysight N6900/N7900 Series Operating and Service Guide 266
6 SCPI Programming Reference
