Parameter Typical Return
(none) <time>
Return the number of triggers: TRIG:ACQ:IND:COUN?
TRIGger:ACQuire:TOUTput[:ENABle] 0|OFF|1|ON
TRIGger:ACQuire:TOUTput[:ENABle]?
Enables measurement triggers to be sent to a digital port pin. The digital port pin must be configured
as trigger output before it can be used as a trigger source (see External Trigger I/O).
Parameter Typical Return
0|OFF|1|ON , *RST OFF 0๎or๎1
Enable sending measurement triggers to digital pins: TRIG:ACQ:TOUT ON
TRIGger:ACQuire:SOURce <source>
TRIGger:ACQuire:SOURce?
Selects the trigger source for the acquisition system:
BUS Selects a remote interface trigger command.
CURRent1 Selects an output current level.
EXTernal Selects ALL digital port pins that have been configured as trigger sources.
EXPRession<1-8> Selects a user-defined expression as the trigger source.
PIN<1-7> Selects a digital port pin configured as a trigger input.
TRANsient1 Selects the transient system as the trigger source.
VOLTage1 Selects an output voltage level.
Parameter Typical Return
BUS|CURRent1 | EXTernal | EXPRession<1-8> |
PIN<1-7> | TRANsient1 | VOLTage1, *RST BUS
BUS, CURR1, EXT, EXPR<n>, PIN<n>, TRAN1,
or VOLT1
Select digital port pin 1 as the measurement trigger source:
TRIG:ACQ:SOUR PIN1
TRIGger:ARB:SOURce <source>
TRIGger:ARB:SOURce?
Selects the trigger source for arbitrary waveforms:
BUS Selects a remote interface trigger command.
EXTernal Selects ALL digital port pins that have been configured as trigger sources.
EXPRession<1-8> Selects a user-defined expression as the trigger source.
IMMediate Triggers the transient as soon as it is INITiated.
PIN<1-7> Selects a digital port pin configured as a trigger input.
Keysight N6900/N7900 Series Operating and Service Guide 278
6 SCPI Programming Reference
