Parameter Typical Return
0 to 102% of rating, *RST 0 <low voltage limit>
Sets the low voltage limit to 2 V: VOLT:LIM:LOW2
l This command is coupled to the VOLTage:LIMit command. The voltage limit must always be pro-
grammed to a higher value than low voltage limit.
l The low voltage limit also prevents the output from turning on when the output voltage is below
the programmed low voltage limit.
[SOURce:]VOLTage:MODE FIXed|STEP|LIST|ARB
[SOURce:]VOLTage:MODE?
Sets the transient mode. This determines what happens to the output voltage when the transient
system is initiated and triggered.
FIXed keeps the output voltage at its immediate value.
STEP steps the output to the triggered level when a trigger occurs.
LIST causes the output to follow the list values when a trigger occurs.
ARB causes the output to follow the arbitrary waveform values when a trigger occurs.
Parameter Typical Return
FIXed|STEP|LIST|ARB, *RST FIXed FIX, STEP, LIST, or ARB
Sets the voltage mode to Step: VOLT:MODE STEP
[SOURce:]VOLTage:PROTection[:LEVel] <value>|MIN|MAX
[SOURce:]VOLTage:PROTection[:LEVel]? [MIN|MAX]
Sets the over-voltage protection level. Units are in volts. If the output voltage exceeds the OVP level,
the output is disabled and the Questionable Condition status register OV bit is set.
Parameter Typical Return
0
t
o
12
0
%
o
f
rati
n
g
,
*RST
12
0%
o
f
rati
n
g
<p
r
o
te
ct
l
e
v
el>
Sets the over-voltage protection to 24 V: VOLT:PROT 24
l An over-voltage condition can be cleared with the OUTput:PROTection:CLEar command after the
cause of the condition has been removed.
[SOURce:]VOLTage:PROTection:LOW[:LEVel] <value>|MIN|MAX
[SOURce:]VOLTage:PROTection:LOW[:LEVel] ? [MIN|MAX]
Prevents the output from turning on if the output voltage is below the low-voltage protection level.
When the low-voltage condition is true, the Questionable Status Register UV bit is set.
Keysight RP7900 Series Operating and Service Guide 237
5 SCPI Programming Reference
