Parameter Typical Return
0 to 102% of rating, *RST 0 <low-voltage protect setting>
Sets the protection level to 2 V: VOLT:PROT:LOW2
[SOURce:]VOLTage:PROTection:LOW:DELay <value>|MIN|MAX
[SOURce:]VOLTage:PROTection:LOW:DELay? [MIN|MAX]
Sets the low-voltage protection delay in seconds. The low-voltage protection function will not be
triggered during the delay time. After the delay time has expired, the low-voltage protection function
will be active. This can be used to prevent false tripping when protection is enabled, as well as
momentary changes in output state from triggering the over-current protection function. The minimum
delay is 20.48 microseconds, and a maximum delay of 2611 seconds.
Parameter Typical Return
0.00002048 – 2611 seconds *RST 20.48 μs <delay value>
Sets the protection delay to 0.2 seconds: VOLT:PROT:LOW:DEL 0.2
[SOURce:]VOLTage:PROTection:LOW:STATe 0|OFF|1|ON
[SOURce:]VOLTage:PROTection:LOW:STATe?
Enables or disables low-voltage protection.
Parameter Typical Return
0|OFF|1|ON, *RST OFF 0or1
Enable the under-voltage protection state: VOLT:PROT:LOW:STAT ON
l A low-voltage condition can be cleared with OUTPut:PROTection:CLEar after the cause of the con-
dition is removed.
[SOURce:]VOLTage:RESistance[:LEVel][:IMMediate][:AMPLitude] <value>|MIN|MAX
[SOURce:]VOLTage:RESistance[:LEVel][:IMMediate][:AMPLitude]? [MIN|MAX]
Sets the output resistance level. Only applies in voltage priority mode. Units are in ohms. Refer to the
RP793xA, RP794xA and RP795xA, RP796xA characteristics for the resistance programming ranges.
Parameter Typical Return
0 to maximum (model dependent) | MIN | MAX, *RST0 0
Specifies an output resistance of 0.5 ohms: VOLT:RES 0.5
l Requires firmware version B.03.02.1232 and up for models RP793xA and RP794xA.
l When units are paralleledd, the programmable output resistance is reduced. The programmable
output resistance for a single unit must be divided by the total number of paralleled units.
5 SCPI Programming Reference
238 Keysight RP7900 Series Operating and Service Guide
