118 Keysight M8194A 120 GSa/s Arbitrary Waveform Generator User Guide
4 Remote Programming
Operation Status Subsystem
The Operation Status register contains conditions which are part of the
instrument’s normal operation.
Table 15 Questionable status register
The following commands access the operation status group.
:STATus:OPERation[:EVENt]?
Reads the event register in the operation status group. It’s a read-only
register. Once a bit is set, it remains set until cleared by this command or
*CLS command. A query of the register returns a decimal value which
corresponds to the binary-weighted sum of all bits set in the register.
Bit Number Decimal Value Definition
0 Not used 1 Returns “0”
1 Not used 2 Returns “0”
2 Not used 4 Returns “0”
3 Not used 8 Returns “0”
4 Not used 16 Returns “0”
5 Not used 32 Returns “0”
6 Not used 64 Returns “0”
7 Not used 128 Returns “0”
8 Run Status 256 Indicates if system is running
9 Not used 512 Returns “0”
10 Not used 1024 Returns “0”
11 Not used 2048 Returns “0”
12 Not used 4096 Returns “0”
13 Not used 8192 Returns “0”
14 Not used 16384 Returns “0”
15 Not used 32768 Returns “0”
