36 Keysight M8194A 120 GSa/s Arbitrary Waveform Generator User Guide
3 M8194A Soft Front Panel
Title Bar
The title bar is a horizontal bar present at the top of a window which
contains standard Window elements such as the program name and the
icons for minimizing, maximizing, or closing the window.
Menu Bar
The menu bar consists of various pull down menus that provide access to
the different functions and launch interactive GUI tools.
The menu bar includes the following pull down menu:
•File
•View
• Utilities
•Tools
•Help
Each menu and its options are described in the following sections.
File Menu
The File menu includes the following selections:
View Menu
The View menu includes the following selections:
File > Connect… Opens the “Connect to Instrument” dialog box. For details, see Launching
the M8194A Soft Front Panel
on page 32.
File > Save Configuration As… Saves the current configuration as a text file.
File > Load Configuration… Loads the previously saved configuration file.
File > Exit Exits the M8194A application.
View > Refresh Reads the instrument state and updates all fields.
View > Hide Minimizes the GUI to the notify icon.
