Voltage Status Subsystem
The Voltage Status register contains the voltage conditions of the
individual channels.
The following SCPI commands and queries are supported:
:STATus:QUEStionable:VOLTage[:EVENt]?
:STATus:QUEStionable:VOLTage:CONDition?
:STATus:QUEStionable:VOLTage:ENABle[?]
:STATus:QUEStionable:VOLTage:NTRansition[?]
:STATus:QUEStionable:VOLTage:PTRansition[?]
Table 16 Voltage status register
Frequency Status Subsystem
The Frequency Status register contains the frequency conditions of the
module. The following SCPI commands and queries are supported:
:STATus:QUEStionable:FREQuency[:EVENt]?
:STATus:QUEStionable:FREQuency:CONDition?
:STATus:QUEStionable:FREQuency:ENABle[?]
:STATus:QUEStionable:FREQuency:NTRansition[?]
:STATus:QUEStionable:FREQuency:PTRansition[?]
Bit Number Decimal Value Definition
0 Voltage warning 1 Output 1 has been switched off (to protect itself)
1 Voltage warning 2 Output 2 has been switched off (to protect itself)
2 Voltage warning 4 Output 3 has been switched off (to protect itself)
3 Voltage warning 8 Output 4 has been switched off (to protect itself)
4 Not used 16 Returns “0”
5 Not used 32 Returns “0”
6 Not used 64 Returns “0”
7 Not used 128 Returns “0”
