Keysight M8194A 120 GSa/s Arbitrary Waveform Generator User Guide 155
Remote Programming 4
SCPI Command Differences Between M8194A and M8196A
This section is intended to the users who are using both M8194A and
M8196A AWGs for waveform generation. Since, most of the SCPI
commands in both the instruments are similar, so the user can use the
same test automation suit, by making few edits. The following table only
lists the differences in the SCPI commands between these two
instruments:
Commands M8194A M8196A
:ARM[:SEQuence][:STARt][:LAYer]:MDELay
:ARM[:SEQuence][:STARt][:LAYer]:TRIGger:LEVel
:ARM[:SEQuence][:STARt][:LAYer]:TRIGger:SLOPe
:INITiate:CONTinuous[:STATe]
:OUTPut{1:4}:ROSCillator:RCD1|RCD
:OUTPut{1:4}:ROSCillator:RCD2
:OUTPut{1:4}:ROSCillator:SCD
:OUTPut{1:4}:ROSCillator:SOURce
[:SOURce]:FREQuency:INT:RASTer
[:SOURce]:FREQuency:RANGe
[:SOURce]:FREQuency:RNG1|RNG:RASTer
[:SOURce]:FREQuency:RNG2:RASTer
[:SOURce]:ROSCillator:FREQuency
[:SOURce]:ROSCillator:RANGe
[:SOURce]:ROSCillator:RNG1|RNG:FREQuency
[:SOURce]:ROSCillator:RNG2:FREQuency
[:SOURce]:ROSCillator:RNG3:FREQuency
[:SOURce]:ROSCillator:SOURce
[:SOURce]:ROSCillator:SOURce:CHECk?
:TRIGger[:SEQuence][:STARt]:BEGin:HWDisable[:STATe]
:TRIGger[:SEQuence][:STARt]:BEGin[:IMMediate]
