9 Programming the Instrument
9.4 Status Register System & STATus Subsystem
Questionable register
Preset 32767
Min 0
Max 32767
Status Bits/OPC
dependencies
Sequential command
Questionable Frequency Event Query
Returns the decimal value of the sum of the bits in the Questionable Frequency
Event register.
NOTE
The register requires that the associated PTRansition or NTRansition filters be
set before a condition register bit can set a bit in the event register. The data in
this register is latched until it is queried. Once queried, the register is cleared.
Remote Command
:STATus:QUEStionable:FREQuency[:EVENt]?
Example
:STAT:QUES:FREQ?
Preset 0
Status Bits/OPC depend-
encies
Sequential command
Questionable Frequency Negative Transition
Determines which bits in the "Questionable Frequency Condition" on page 2602
register will set the corresponding bit in the "Questionable Frequency Event Query"
on page 2603 register when the condition register bit has a negative transition (1 to
0).
The variable <integer> is the sum of the decimal values of the bits that you want to
enable.
Remote
Command
:STATus:QUEStionable:FREQuency:NTRansition <integer>
:STATus:QUEStionable:FREQuency:NTRansition?
Example
:STAT:QUES:FREQ:NTR 2
Frequency Reference ‘regained lock’ will be reported to the Frequency Summary of the Status
Questionable register
Preset 0
Min 0
Max 32767
2603 Vector Modulation Analyzer Mode User's &Programmer's Reference
