Keysight N9000B - IF Path; 3.2.8.5 Meas Time

3 VMA Mode
3.2 Custom OFDM Measurement
IF Path
Specify IF path manually for each component carriers.
Remote Command
[:SENSe]:OFDM:CCARrier[0]|1|…|7:RF:CHANnel1|…|8:IFPath B10M | B25M | B40M |
B85M | B125M | B140M | B160M | B255M | B510M | B1G | B1500M | B2G | B4G |
EXT
[:SENSe]:OFDM:CCARrier[0]|1|…|7:RF:CHANnel1|…|8:IFPath?
Example
:OFDM:CCAR0:RF:CHAN1:IFP B160M
:OFDM:CCAR0:RF:CHAN1:IFP?
Notes
Option Path
B10M 10 MHz
B25M 25 MHz
B40M 40 MHz
B85M 85 MHz
B125M 125 MHz
B140M 140 MHz
B160M 160 MHz
B255M 255 MHz
B510M 510 MHz
R10 1 GHz
R15 1.5 GHz
R20 2 GHz
R40 4 GHz
EXT Depends on hardware
In cases where the path is not available but is selected from SCPI, error -241,”Hardware missing;
Option not installed” is generated
Dependencies Grayed-out if IF Path Auto is On
Preset Automatically selected IF path according to measurement required IFBW and available HW bandwidth
State Saved Saved in instrument state
3.2.8.5 Meas Time
Lets you set time parameters of the measurement.
Vector Modulation Analyzer Mode User's &Programmer's Reference 502
