3 VMA Mode
3.4 IQ Waveform Measurement
Command
:CALCulate:WAVeform:MARKer[1]|2|…|12:FUNCtion:BAND:RIGHt?
Example
:CALC:WAV:MARK12:FUNC:BAND:RIGH 1 s
:CALC:WAV:MARK12:FUNC:BAND:RIGH?
Notes You must be in the IQ Waveform measurement to use this command
Couplings Changing Interval Right necessarily changes "Interval Left" on page 754 and "Interval Span" on page
754
Preset 5% of Meas Time
State Saved Yes
Min 0
Max 100 s
3.4.7.6 Properties
The controls on this tab are used to set certain properties of the selected marker.
Marker Time
This is the fundamental control that you use to move a marker around on the trace.
It is the same as "Marker Time" on page 745 in Settings.
Relative To
Selects the marker to which the selected marker is relative (its reference marker).
Every marker has another marker to which it is relative. This marker is referred to as
the “reference marker” for that marker. This attribute is set by the Marker,
Properties, Relative To key. The marker must be a Delta marker to make this
attribute relevant. If it is a Delta marker, the reference marker determines how the
marker is controlled and how its value is displayed. A marker cannot be relative to
itself.
Remote
Command
:CALCulate:WAVeform:MARKer[1]|2|…|12:REFerence <integer>
:CALCulate:WAVeform:MARKer[1]|2|…|12:REFerence?
Example
:CALC:WAV:MARK:REF 8
:CALC:WAV:MARK:REF?
Notes This command causes the marker specified with the subopcode to become selected
A marker cannot be relative to itself so that choice is not available, and if sent from SCPI generates
error -221: “Settings conflict; marker cannot be relative to itself”
When queried, a single value is returned (the specified marker number’s relative marker)
Couplings The act of specifying the selected marker’s reference marker makes the selected marker a Delta marker
755 Vector Modulation Analyzer Mode User's &Programmer's Reference
