KI Tributaire Lecterns - Mini-Tap Power Module Installation (Optional)

14
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Tributaire™ Collection - Lecterns
Assembly Instructions
Figure 19
Mini-Tap
power module
with 3-prong plug
storage
cabinet
#10-12 x /”
5
8
Phillips pan
head screws
Mini-Tap
power module
with 3-prong plug
Detail V - (underside view)
Mini-Tap Power Module
Installation (optional)
1. Open the doors on the storage
cabinet if not open already
(Figure 19).
2. Align the mounting holes of the
Mini-Tap power module with the
pre-drilled mounting holes
underneath the top of the storage
cabinet. Secure the Mini-Tap
power module to the top using
four #10-12 x
5
/
8
” Phillips pan head
screws (Detail V).
