KI Tributaire Lecterns - Screw-Adjustable Height Lectern- Storage Cabinet Installation

7
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Tributaire™ Collection - Lecterns
Assembly Instructions
Detail
F
11
/ -20 x /”
42
socket head
cap screws
base
assembly
lectern
upright
( -adjustablescrew
height)
Detail
H
storage
cabinet
lower lectern
cabinet mount
plate
#10-16 x /”
5
8
Phillips truss
head screw
Detail
G
storage
cabinet
upper
lectern
cabinet
mount
plate
#10-16 x /”
5
8
Phillips truss
head screw
base
assembly
lectern upright
( -adjustablescrew
height)
Figure 5
11
/ -20 x /”
42
socket head
cap screw
Figure 6
base
assembly
lower lectern
cabinet mount
plate
upper lectern
cabinet mount
plate
storage
cabinet
Screw-Adjustable Height Lectern -
Storage Cabinet Installation
1. Carefully place the base assembly
onto it’s back, non-user side, on a
soft, protective surface (Figure 5).
2. Remove the two
1
/
4
-20 x
1
/
2
” Allen
cap screws from the base assembly
(Figure 5 & Detail F).
3. Pull out and remove the lectern
upright from the base assembly.
Set the lectern upright aside to be
re-installed at a later step (Figure 5).
4. Carefully place the storage cabinet
onto it’s back on a soft protective
surface. Align the opening on the
underside of the cabinet with the top
of the base assembly, then insert the
upper lectern cabinet mounting plate
into the storage cabinet until the
bottom of the cabinet rests on top of
the lower lectern cabinet mount plate
(Figure 6).
5. Open the storage cabinet doors
to gain access inside. Algin the
mounting holes of the upper lectern
cabinet mount plate to the mounting
holes on the underside of the storage
cabinet top, then secure together
using seven #10-16 x
5
/
8
” Phillips
truss head screws (Detail G).
6. Align the mounting holes on the
lower lectern cabinet mount plate
with the mounting holes of the
underside of the storage cabinet,
then secure together using eight
#10-16 x
5
/
8
” Phillips truss head
screws (Detail H).
