1. Engine coolant reservoir....................8-41
2. Engine oil filler cap ............................8-39
3. Brake/clutch fluid reservoir ................8-45
4. Air cleaner .........................................8-49
5. Fuse box............................................8-77
6. Negative battery terminal ..................8-56
7. Positive battery terminal ....................8-56
8. Engine oil dipstick..............................8-38
9. Radiator cap ......................................8-43
10. Windscreen washer fluid reservoir ..8-46
OCD078002R
■
SmartStream D 1.6 Engine (Diesel)
❈ The actual engine room in the vehicle may differ from the illustration.
28
Your vehicle at a glance
