Maintenance
3. Remove the socket from the
assembly by turning the socket
counterclockwise until the tabs on
the socket align with the slots on
the assembly.
4. Remove the bulb from bulb-socket
by pulling it out.
5. Insert a new bulb by inserting it
into the bulb-socket.
6. Install the socket in the assembly
by aligning the tabs on the socket
with the slots in the assembly.
Push the socket into the assembly
and turn the socket clockwise.
7. Install the service cover by putting
it into the service hole.
Stop and tail lamp (LED type)
bulb replacement (Rear combi-
nation lamp Type B)
If the stop and tail lamp (LED) (1,2)
does not operate, have your vehicle
checked by a professional workshop.
Kia recommends to visit an autho-
rised Kia dealer/service partner.
The LED lamp cannot be replaced
as a single unit because it is an inte-
grated unit. The LED lamp has to be
replaced with the unit.
A skilled technician should check or
repair the stop and tail lamp (LED),
for it may damage related parts of
the vehicle.
Rear fog lamp (LED type) bulb
replacement (Rear combina-
tion lamp Type B)
If the rear fog lamp (LED) (1) does
not operate, have your vehicle
checked by a professional workshop.
Kia recommends to visit an autho-
rised Kia dealer/service partner.
The LED lamp cannot be replaced
as a single unit because it is an inte-
grated unit. The LED lamp has to be
replaced with the unit.
A skilled technician should check or
repair the rear fog lamp (LED), for it
may damage related parts of the
vehicle.
OCD078060
OCD078061 OCD078062
