Kia Ceed - Page 659

893
Maintenance
Fuse Name Symbol Fuse rating Circuit Protected
ECU 4
E4
15A
[Kappa 1.4L MPI] -
[Kappa 1.0L T-GDI] ECM (Engine Control Module)
[Kappa 1.4L T-GDI] ECM (Engine Control Module)
[Gamma 1.6L MPI] ECM (Engine Control Module)/PCM (Power train Control Module)
[SmartStream D 1.6] ECM (Engine Control Module)
WIPER 25A
[Kappa 1.4L MPI] Wiper Relay
[Kappa 1.0L T-GDI] Wiper Relay
[Kappa 1.4L T-GDI] Wiper Relay
[Gamma 1.6L MPI] Wiper Relay
[SmartStream D 1.6] Wiper Relay
HORN 15A
[Kappa 1.4L MPI] Horn Relay
[Kappa 1.0L T-GDI] Horn Relay
[Kappa 1.4L T-GDI] Horn Relay
[Gamma 1.6L MPI] Horn Relay
[SmartStream D 1.6] Horn Relay
