Maintenance
vehicle condition
Head lamp (Halogen type) Head lamp (LED type)
Ground Height Distance between lamps Ground Height Distance between lamps
Lowbeam High beam Lowbeam High beam Low/High beam Low/High beam
H1 H2 W1 W2 H1' W1'
without driver
[mm(in)]
706 (27.8) 684 (26.9) 1,344 (52.9) 1,112 (43.8) 712 (28) 1,354 (53.3)
with driver
[mm(in)]
700 (27.6) 678 (26.7) 1,344 (52.9) 1,112 (43.8) 706 (27.8) 1,354 (53.3)
vehicle condition
Front Fog lamp (Bulb type)
Ground Height Distance between lamps
H3 W3
without driver
[mm(in)]
490 (19.3) 1,494 (58.8)
with driver
[mm(in)]
486 (19.1) 1,494 (58.8)
■
5 Door (Standard model)
